Two Stage Technology

Two StagePiston Compressors

High-efficiency two stage reciprocating compressors with intercooling for demanding industrial applications requiring higher pressures and continuous operation.

Get Quote Back to Piston Range

Advanced Features

Engineered with advanced two-stage compression technology for superior performance.

Intercooler Design

Advanced intercooling system for maximum efficiency and lower operating temperatures

Heavy Duty Construction

Robust cast iron construction designed for continuous heavy-duty operation

High Efficiency

Two-stage compression delivers superior efficiency and higher pressures

Advanced Controls

Sophisticated control systems for optimal performance and protection

Why Choose Two Stage?

Two stage piston compressors offer significant advantages over single stage units for demanding applications.

Higher pressure capability up to 14 Bar

Better efficiency compared to single stage

Lower operating temperatures with intercooling

Suitable for continuous duty applications

Reduced power consumption per CFM

Longer service life due to lower compression ratios per stage

Technical Specifications

Two Stage Piston Compressor Specifications

Power Range:5 HP to 25 HP

Pressure Range:Up to 14 Bar (203 PSI)

Air Delivery:18 to 90 CFM

Cooling:Air Cooled with Intercooler

Drive Type:Belt Driven

Tank Options:300L to 1000L

Available Models

Choose from our range of two stage piston compressors for high-pressure applications.

SJ-TS-5HP

Power:5 HP

Pressure:14 Bar

Air Delivery:18 CFM

Tank Size:300L

Applications:

Industrial ManufacturingHeavy WorkshopProduction Line

SJ-TS-10HP

Power:10 HP

Pressure:14 Bar

Air Delivery:35 CFM

Tank Size:500L

Applications:

Large IndustrialManufacturing PlantHeavy Machinery

SJ-TS-15HP

Power:15 HP

Pressure:14 Bar

Air Delivery:55 CFM

Tank Size:750L

Applications:

Heavy IndustrialMining OperationsLarge Manufacturing

SJ-TS-25HP

Power:25 HP

Pressure:14 Bar

Air Delivery:90 CFM

Tank Size:1000L

Applications:

Heavy Duty IndustrialContinuous OperationLarge Scale Production

Need High Pressure Air Solutions?

Get expert consultation to select the perfect two stage piston compressor for your high-pressure applications.

Get Free Consultation View Multi-Stage Models
